ดิจิตอลแคลมป์มิเตอร์ 3286-01

คุณสมบัติสินค้า:

SKU : HIOKI

ดิจิตอลแคลมป์มิเตอร์ CLAMP ON POWER HiTESTER 3286-20 Functionality and Safety Packed into a Handheld Unit

Share

Share

CLAMP ON POWER HiTESTER 3286-20
Functionality and Safety Packed into a Handheld Unit

  • Single phase 600 kW & up to 20th Harmonic levels measurement
  • Active/ reactive/ apparent power, Power factor, Phase detection, Frequency, Harmonic waveform value, or Waveform peak value
  • Simple checking of three-phase lines (Should be balanced and no distortion)

ORDER CODE : 3286-01

  • Measurement line : Single-phase, Three-phase (balanced with no distortion)
  • Measurement items : Voltage, Current, Voltage/ current peak, Active/ reactive/ apparent power, Power factor, Phase angle *1, Reactivity, Frequency, Simple Active Energy Consumption (Single-phase) [CM3286-01 only*2] Voltage/ current harmonic levels
  • AC voltage : [Measurement range] 80.0 V to 600.0 V, Single range,
  • Basic accuracy 45 - 66 Hz: ±0.7% rdg. ±3 dgt. (Frequency characteristics: 45 to 1 kHz, True RMS)
  • AC current : [Measurement range] 0.060 A to 600.0 A, 3 range,
  • Basic accuracy : ±1.3% rdg. ±3dgt. (Frequency characteristics: 45 to 1 kHz, True RMS)
  • Power : [Single phase] 0.005 kW to 360.0 kW
  • Basic accuracy: ±2.0% rdg. ±7 dgt. (50/ 60 Hz, Power factor=1)
    • [Balanced three-phase 3-wire] 0.020 kW to 623.5 kW
  • Basic accuracy: ±3.0% rdg. ±10 dgt. (50/ 60 Hz, Power factor=1)
    • [Balanced three-phase 4-wire] 0.040 kW to 1080 kW
  • Basic accuracy: ±2.0% rdg. ±3 dgt. (50/ 60 Hz, Power factor=1)
  • Harmonic levels (CM3286-01only *2) : Voltage/ current harmonic levels up to 30th, Content factor,
  • Total harmonic distortion ratio
  • Interface : Bluetooth® 4.0LE, Display of measured values on an iOS device or an Android device
  • Power supply : LR03 Alkaline battery ×2
  • Core jaw dia. : φ 46 mm (1.81 in)
  • Dimensions and mass : 82 mm (3.23in) W × 241 mm (9.49in) H × 37 mm (1.46in) D, 450 g (15.9 oz)
  • Accessories : Connection cord L9257 ×1, LR03 Alkaline battery ×2, Carrying case C0203 ×1, Instruction manual ×1
    • [CM3286-01 only]Notice Regarding Equipment That Emits Radio Waves ×1



** สินค้าจริงอาจแตกต่างจากภาพในหน้าจอ เนื่องจากการจัดแสงในการถ่ายภาพ การแสดงผลของหน้าจอ และการผลิตในแต่ละล็อต ทางบริษัทฯขอสงวนสิทธิ์ไม่รับเปลี่ยน/คืนสินค้า **
